XY7100
XY7100 is a highly integrated IoT NTN chip, which supports 3GPP R17 IoT-NTN, and is compatible with R14 NB-IoT
Product Advantage
-
-
Simultaneously supports NB-IoT and NTN
Flexibly switching network modes based on signal conditions to ensure service quality
-
SDR architecture
Based on an SDR architecture design, it can be customized to meet more requirements
-
Highly integrated
Integrate a PA, featuring low-cost and ultra-low power consumption capability
-
Reliable supply
QFN52 6x6
Proven process, rich production capacity
Pure domestic supply chain
Fully self-developed IP, no risk of infringement
-
Basic Parameter
-
-
Communication protocol
R13, R14, R17
-
Processor
ARM Cortex - M3; 106Mhz
-
Encapsulation
6mm*6mm QFN52
-
Frequency band
Bands 1/3/5/8/20/28/255/256
-
Hardware peripheral
UART/CSP/GPIO/ADC/I2C/SPI etc.
-
Operating temperature
-40°C to +85°C
-
